S-CS9X200 Space-Saver 'SX' Filtration Systems

Material: CPVC
Material: EPDM
Size: 30"
Inlet: 1NPT
Outlet: 1NPT
Flow(max) (GPH): 960 GPH
Press.(max) (psi): 15 psi
Media: 3 x 30" Double Open End Filter Cartridge / 3
Power (hp): 0.2 hp
Chamber: Series 'S' Plastic Filter Chambers
Capacity: 0.98m²
Total Capacity: 31.5ft²
RPM: 3450
Electric Data: 100-110V/1/50-60
Pump: Series 'X' Magnetic Coupled Pumps
Seal Type: Magnet coupled
Bushing: Rulon / Alumina

Call

SKU: S-CS9X200 Category: Space-Saver SX

Product Literature

Product Bulletin

F-213 Space-Saver 'SX' Filtration Systems

Parts List

P-0776 Space-Saver 'SX', 'SM' and 'SME' Filtration Systems

Operation and Service Guide

O-0884 Series 'LX', 'SX', 'SM', 'J' and 'GJ'
